Trina 450 TSM-NEG9R.28 Vertex S+ Doppelglas

Vertex S+ 450 watts n-type module, black frame

Trina is launching the new Vertex S+ series of PV modules. The Vertex S+ series is Trina's first product to offer a 25-year product warranty at launch. The new high-performance module achieves an output power of up to 450 W with small space requirements. Multi-busbar technology is integrated, which serves to improve the light-catching effect, reduce series resistance and improve current consumption. This double glass module has a performance guarantee of 30 years. The Vertex S+ series is flexible in use and intended for both residential and commercial applications.

Product advantages

• Excellent resistance to fire and in difficult environmental conditions
• N-type technology with 1% degradation in the first year and 0.4% in years 2-30
• Multi busbar technologie
• 30 mm frame height, very stable
• System design and planning is exactly the same as previously known
• 25 years product warranty on manufacturing
• 30 years performance guarantee

Hail resistance class 3

Product features Trina 450 TSM-NEG9.28 Vertex S+ double glass

• 450 Wp
• 144 mono-crystalline cells
• Efficiency: 22.5 %
• Black module frame
• White back sheet
• Dimensions: 1762 × 1134 × 30 mm (H x W x D)
• Weight: 21.0 kg
• Connector: MC4 EVO
• Cable length at the module: 1100 mm (vertical orientation)
• Snow load up to 5,400 Pa
• Wind load up to 4,000 Pa
• Power temperature coefficient: -0.30%/°C
• Does NOT have A1 fire safety certificate
• New frame variation B (see data sheet)
