Pylontech Force H1 10.65 kWh
| Type of manufacturer: | Force-H1-48/144V |
|---|---|
| Art. Nr.: | 11246 |
| Battery type: | High volt lithium-iron-phosphate |
| Net capacity: | 10.12 kWh |
| Phases: | 1 |
| Solar battery type: | High voltage battery |
Prices are only visible to business customers upon successful registration.
Available from stock
Product number:
11246
Description
Batterie Pylontech Force H1 10.65 kWh
The Pylontech Force H1 battery is a high-voltage storage system from Pylon. The newly designed system makes it easy to connect the battery modules together and saves installers valuable time. The stacking system offers flexible configurations from 144 V to 336 V and capacities from 10.65 kWh to 149.1 kWh. Thanks to its broad compatibility with well-known inverter manufacturers such as Kostal, the Pylontech storage system can be installed in various combinations.
Product advantages Pylontech Force-H1 10.65 kWh
- Flexible modular design
- 10 years of warranty
- Broad inverter compatibility
- 95% DOD
Product features Pylontech Force-H1 10.65 kWh
- Net capacity: 9.59kWh
- Rated voltage: 144V
- Charging/discharging current: 37A
- Max. Charging/discharging current: 40A (15sec.)
- Lithium iron phosphate cells (LFP)
- Protection category: IP55
- Communications: CAN, RS485
- Weight: 122kg
- Dimensions: 600x380x700 mm (WxHxD)
Scope of delivery
- 1x FC0500-40S-V2 Force-H1 BMU control unit
- 3x FH48074 Force-H1 battery module
Examples of compatibility:
- Sungrow SHxRT
- SMA SBS
- Goodwe EH/ET/BT/BH
- Kostal Plenticore Plus/G2/BI
